China Manufacturer +80 Mesh +100 Mesh High Carbon 98% Natural Expanded Graphite Used in Machinery
Can be expanded graphite sheet expansion characteristics different from other kinds of expansion agent, heated to a certain temperature, due to absorption in interlayer matrix compound decomposition, began to swell, expansible graphite as starting expansion temperature, expansion completely in 1000 °C, the maximum volume. Inflation can reach above 200 times -300 times of the initial volume. After expansion of graphite is called expanded graphite or graphite worms, the original scaly into low density worm-like, formed a very good insulation blanket. Expanded graphite is a carbon source in the inflation system, and thermal barrier, can effective heat insulation, with in the fire heat release rate is low, the quality loss is small, the characteristics of the produced less smoke.
Expanded graphite is a kind of good performance of the adsorbent, especially it has a porous structure, has strong adsorption capacity for organic compounds, expanded graphite can be 1 g 80 g of oil adsorption, thus expanded graphite was designed to all kinds of industrial oil and industrial oil absorbents.
Expanded graphite extremely easy adsorption of oils, organic molecules and hydrophobic substances, used for water environmental treatment has irreplaceable effect to other substances. When it is used for the surface oil removal in granular form, according to the size of the water in oil area and the type of the oil, its dosage is 1 ~ lo % / rn, adsorption time in 15 rain to several hours.
Compared with other sorbents, expanded graphite has many advantages. If use activated carbon for water oil removal, it will sink after adsorption of oil, the adsorption quantity is too small, and not easy to recycle; And some adsorbent, such as cotton, hay, polypropylene fiber, perlite, vermiculite and so on, they are on the oil absorption of the water absorption at the same time, it brings to the post-processing difficult; Expanded graphite on oil adsorption quantity is large, floating in the water after oil absorption, easy to catch recycling, recycling processing is simple, can use extrusion, centrifugal separation, vibration, solvent cleaning, burning and heating extraction method, and no second pollution formed.
Features:
1) strong pressure resistance, flexibility, plasticity and self lubrication;
2) of high and low temperature resistance, corrosion resistance, resistance to radiation characteristics;
3) Strong seismic characteristics;
4) strong conductivity;
5) Strong anti-aging properties, resistance to distortion;
6) Can resist all kinds of metal melting and infiltration;
Typical Grades
| Grade Name | Mesh | Expansion Ratio (cc/g) | Purity
(%) | Moisture
(%) | PH | Sulfur
(ppm) | Onset Temp
(°C) | Application |
| HS555 | +50 | 250:1 | 95-97 | <1 | 6-9 | * | 160-180 | PU foam, Bituman. |
| HS855 | +50 | 250:1 | 98-99 | <1 | 6-9 | * | 160-180 | PU foam, Bituman. |
| HS955 | +50 | 250:1 | 99-99.5 | <1 | 6-9 | * | 160-180 | PU foam, Bituman, for application require least instruments damage. |
| HS085 | +80 | 250:1 | 90-95 | <1 | 6-9 | * | 160-180 | PU foam, EPS foam, XPS foam, sealing strip. |
| HS585 | +80 | 250:1 | 95-97 | <1 | 6-9 | * | 160-180 | PU foam, EPS foam, XPS foam, sealing strip. |
| HS055 | +50 | 250:1 | 90-95 | <1 | 6-9 | * | 160-180 | PU foam, EPS foam, XPS foam, sealing strip. |
| HS988 | +80 | 180:1 | 99-99.5 | <1 | 6-9 | <1500 | * | Graphite foil, roll, gaskets. |
| HS980HP | +80 | 200:1 | 99.5-99.8 | <1 | 6-9 | <1500 | * | Graphite foil, roll, gaskets. |
| HS980UHP | +80 | 200:1 | >99.9 | <1 | 6-9 | <1500 | * | Battery. |
| HS557 | +50 | 270:1 | 95-97 | <1 | 6-9 | * | 160-180 | Steel oxygen protection. |
| HS611 | -100 | 100:1 | 96-98 | <1 | 6-9 | * | 160-180 | Fireproof textile. |
| HS223 | -200 | 30:1 | 92-95 | <1 | 6-9 | * | 160-180 | Thin coating. |
| HS5HE | +50 | 350:1 | 95-97 | <1 | 6-9 | * | 160-180 | Collar pillar. |
| HS9HE | +50 | 350:1 | 99-99.5 | <1 | 6-9 | * | 160-180 | Collar pillar, for application require least instruments damage. |
| HS558HT | +50 | 180:1 | 95-97 | <1 | 6-9 | * | 220 | Mixing, extruding or processing
at higher temperatures. Used as fire-retardant additive in PE,
PP, and HIPS. |
| HS558UHT | +50 | 180:1 | 95-97 | <1 | 6-9 | * | 250 | Processing temperatures are very high. Used as fire-retardant additive in PE,
PP, and HIPS. |
- Special grades with different specs are also available on request. Please contact us for details.
